IC Capture - Image Acquisition and Image Measurement

Image acquisition and powerful tools for the manual measurement of circles, lines, polygons and angles. The convenient user interface enables easy measurement of lengths, angles and surfaces directly from the image displayed on the monitor. Measurement data can be exported as a CSV file.

Starting with version 4, a GenTL producer is required to access the camera

IC Capture - Image Acquisition and Image Measurement

Version 4.0.0.393

	Released	Size	Type	Requirements
	January 30, 2025	52.3 MB		Windows 10 64 bit, Windows 11 64 bit, Linux Ubuntu 20.04 LTS or newer x86_64 CPU: Latest Intel® Core™ i3 (or better) or equivalent AMD® 64-Bit processor (AVX2 support recommended) aarch64 CPU: Armv8-A with AArch64 support. ARM processors used on NVIDIA Jetson modules (or better) or equivalent Minimum 4 GB RAM GPU with OpenGL 3.3 support Driver: The Imaging Source GenTL Producer

Changelog

Merger of the popular IC Capture and IC Measure end use software tools into IC Capture 4

Initial release for Linux x86_64 and Linux ARM 64-bit

DOWNLOAD

Version 2.5.1557.4007

	Released	Size	Type	Requirements
	May 16, 2023	9.6 MB	EXE	Intel Core i3 or similar, 4 GB RAM Windows 7 (32 & 64 bit), Windows 8 (32 & 64 bit), Windows 10 (32 & 64 bit), Windows 11

Changelog

Added new export function "Export Device State" which exports an xml file that can be loaded by IC Imaging Control.

DOWNLOAD

Version 2.5.1547.4007

	Released	Size	Type	Requirements
	February 10, 2021	9.7 MB	EXE	Intel Core i3 or similar, 4 GB RAM Windows 7 (32 & 64 bit), Windows 8 (32 & 64 bit), Windows 10 (32 & 64 bit), Windows 11

Changelog

Added MP4 container for video capture.

Added WMV container for video capture.

Added built in h264 and h265 codecs.

DOWNLOAD

Version 2.5.1525.3931

	Released	Size	Type	Requirements
	May 11, 2020	9.7 MB	EXE	Intel Core i3 or similar, 4 GB RAM Windows 7 (32 & 64 bit), Windows 8 (32 & 64 bit), Windows 10 (32 & 64 bit), Windows 11

Changelog

IC Capture 2.5 is built as a 64-bit application.

Display warning messages for common system misconfigurations, e.g. missing USB drivers.

Reduced CPU load, especially when using multiple high-resolution cameras.

Improved renderer performance.

Display frame statistics in the status bar.

Fixed corrupted toolbar icons in 125% UI scaling mode.

DOWNLOAD

Version 2.4.642.2631

	Released	Size	Type	Requirements
	February 9, 2017	4.8 MB	EXE	Intel Core i3 or similar, 4 GB RAM Graphics card with 24 or 32 bit Windows XP, Windows Vista, Windows 7 (32 & 64 bit), Windows 8 (32 & 64 bit), Windows 10 (32 & 64 bit), Windows 11 DirectX 9.0c or higher

Changelog

RGB64 video format saving as TIFF resulted in a black image. This is fixed now.

DOWNLOAD

Version 2.4.633.2555

	Released	Size	Type	Requirements
	February 11, 2016	4.8 MB	EXE	Intel Core i3 or similar, 4 GB RAM Graphics card with 24 or 32 bit Windows XP, Windows Vista, Windows 7 (32 & 64 bit), Windows 8 (32 & 64 bit), Windows 10 (32 & 64 bit), Windows 11 DirectX 9.0c or higher

Changelog

Minor changes.

DOWNLOAD

Version 2.4.612.2455

	Released	Size	Type	Requirements
	October 14, 2015	4.3 MB	EXE	Intel Core i3 or similar, 4 GB RAM Graphics card with 24 or 32 bit Windows XP, Windows Vista, Windows 7 (32 & 64 bit), Windows 8 (32 & 64 bit), Windows 10 (32 & 64 bit), Windows 11 DirectX 9.0c or higher

Changelog

Bugfix: Fixed a crash when using vignetting effect on RGB24 video format.

DOWNLOAD

Version 2.4.611.2455

	Released	Size	Type	Requirements
	October 5, 2015	4.3 MB	EXE	Intel Core i3 or similar, 4 GB RAM Graphics card with 24 or 32 bit Windows XP, Windows Vista, Windows 7 (32 & 64 bit), Windows 8 (32 & 64 bit), Windows 10 (32 & 64 bit), Windows 11 DirectX 9.0c or higher

Changelog

Added "WDR" button to the toolbar. This button simultaneously enables 16-bit image capture, tone mapping and highlight reduction.

Ctrl+Mousewheel zooms the view, focusing on the cursor position.

Holding down the middle mouse button allows scrolling in the live view.

Improved handling of DFG/HDSDI by auto-selecting video format and frame rate depending on the video source's format.

Use DirectX 11 for video rendering, if available.

DOWNLOAD

Version 2.4.577.2337

	Released	Size	Type	Requirements
	March 10, 2015	4.3 MB	EXE	Intel Core i3 or similar, 4 GB RAM Graphics card with 24 or 32 bit Windows XP, Windows Vista, Windows 7 (32 & 64 bit), Windows 8 (32 & 64 bit), Windows 10 (32 & 64 bit), Windows 11 DirectX 9.0c or higher

Changelog

New device selection dialog, that shows firmware and driver version.

New False Colors effect. Known problem in Windows XP: The buttons in the property dialog do not show the selected colors.

New Perspective Distortion effect.

New Vignetting effect.

DOWNLOAD

Version 2.3.394.1917

	Released	Size	Type	Requirements
	May 8, 2014	2.3 MB	EXE	Intel Core i3 or similar, 4 GB RAM Graphics card with 24 or 32 bit Windows XP, Windows Vista, Windows 7 (32 & 64 bit), Windows 8 (32 & 64 bit), Windows 10 (32 & 64 bit), Windows 11 DirectX 9.0c or higher

Changelog

Added handling of new properties of GigE and USB cameras.

DOWNLOAD
